VP-440 - Overview

 Powerful audio features via DSP technology including audio equalization,

mixing, delay and so on

 Built-in ProcAmp - color, hue, sharpness, noise, contrast and brightness

 Supports 4:4:4 (RGB and YUV) as well as 4:2:2 (YUV) color sampling in

Native mode

 Maintains constant output sync – there is no disruption on the output while

switching between inputs and when no video is detected

 Dedicated RS-232 port for bidirectional data tunneling via HDBT

 Front panel lockout

 Non-volatile memory – saves final settings

Control your VP-440:

 Directly, via the front panel push buttons

 By RS-232 serial commands transmitted by a touch screen system, PC, or

other serial controller

 Via the OSD (on-screen display)

 Via remote contact-closure switches

 Via the Ethernet with built-in Web pages

The VP-440 is housed in a 1/2 19" 1U enclosure, letting 2 units to be rack mounted

side-by-side in a 1U rack space with the optional RK-1 universal rack adapter.

3.1 Using Twisted Pair Cable for HDBT

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; BC−HDKat6a (CAT 6 23 AWG cable) significantly

outperforms regular CAT 5 / CAT 6 cables.

We strongly recommend that you use shielded twisted pair cable.
