VP-440 - Using the Embedded Web Pages

There are eight Web pages:

 The Input Select page (see Section 6.2)

 The Device Settings page (see Section 6.3)

 The Output Settings page (See Section 6.4)

 The HDCP page (see Section 6.5)

 The EDID page (see Section 6.6)

 The Audio page (see Section 6.7)

 The Advanced page (see Section 6.8)

 The About page (see Section 6.9)

6.2 The Input Select Page

Figure 13 shows the Input Select page that is also the first Web page. The column

on the left shows the Input Select page selected and below a list of all the other

available Web pages. The Input Select area lets you select an input to the outputs

(audio, video or audio-follow-video) the Audio out (below Output) shows the audio

input that is routed to the line and monitor outputs. The volume area lets you control

the Line and Monitor output audio level. Click to freeze the video on the output

and click to set to a blank screen.

Click the power icon on the top right side to set the device to the standby mode.

The model name, FW version and IP number appear on the lower left side of the

main page. The lower part of the screen lets you save the settings and upload a

saved setting.
