VP-440 - Controlling the VP-440
15
15
Mode
Function
AUTO
SWITCHING
MODE
Set the auto switching mode to OFF, AUTO SCAN or
LAST CONNECTED. SCAN PRIORITY (below) is
enabled when AUTO SCAN is selected
When one of the auto switching modes is selected
(AUTO SCAN or LAST CONNECTED), audio is
enabled only when a video signal is detected
SCAN PRIORITY
Set to HDMI to begin scanning with HDMI1 or to PC
to begin scanning with PC1
ETHERNET
IP MODE
Set the IP mode to DHCP or STATIC
STATIC IP ADDRESS (fill in if STATIC (above) is selected):
IP ADDRESS
Enter the IP address
SUBNET
Enter the subnet
GATEWAY
Enter the gateway
CONTROL PORT
Enter the control port
MAC ADDRESS
MAC address
LOCK MODE
ALL
Lock all the front panel buttons
MENU ONLY
Lock the MENU (and navigation) front panel buttons
only
ALL & SAVE
Lock all the front panel buttons.
The lock status is saved when the VP-440 is powered
down
MENU ONLY AND
SAVE
Lock the MENU (and navigation) front panel buttons
only.
The lock status is saved when the VP-440 is powered
down
TIMING SHIFT
Set to ON (recommended):
Implements a small shift on the horizontal sync to improve output picture
stability. Set to OFF if the display shows an instability at the selected
output resolution
FACTORY RESET
Select NO or YES
INFORMATION
Displays the INPUT and OUTPUT resolutions, INPUT and OUTPUT HDCP
status, the IP ADDRESS and the FIRMWARE revision number
5.3 Connecting to the VP-440 via RS-232
The VP-440 features two RS-232 ports:
RS-232 DATA (Tx, Rx, GND) to pass data to and from the machine that is
connected to the HDBT connector
RS-232 CTRL (Tx, Rx, GND) to control the VP-440
To connect to the VP-440 via RS-232 connect the RS-232 Terminal block connector on
the product to the RS-232 9-pin D-sub port on your PC/controlled device:
