Kramer VP-440 [44/59] Kramer protocol 3000 detailed commands
![Kramer VP-440 [44/59] Kramer protocol 3000 detailed commands](/views2/1153515/page44/bg2c.png)
VP-440 - The RS-232/Ethernet (UDP) Communication Protocol
39
39
Command
Short Form
Description
#MIC-GAIN?
Get the microphone gain
#TLK
Set audio talkover mode status
#TLK?
Get audio talkover mode status
MIC-TLK
Set mic talkover parameters
MIC-TLK?
Get mic talkover parameters
#STANDBY
Set Standby mode
#STANDBY?
Get Standby mode status
8.3 Kramer Protocol 3000 – Detailed Commands
This section describes the detailed commands list (see Section 8.3.3) as well as the
Port number key (see Section 8.3.1) and the video resolutions key (see
Section 8.3.2).
8.3.1 Port Number Key
Video
#
Audio input
#
Video Output
#
HDMI 1
0
HDMI 1
0
HDMI 1
0
HDMI 2
1
HDMI 2
1
HDBT
1
HDMI 3
2
HDMI 3
2
HDMI 4
3
HDMI 4
3
PC 1
4
PC 1
4
PC 2
5
PC 2
5
8.3.2 The Output Resolutions key
Number
Resolution
Number
Resolution
200
640x480 @60Hz
212
1920x1080 @60Hz
201
800x600 @60Hz
213
1920x1200 @60Hz
202
1024x768 @60Hz
214
480p @60Hz
203
1280x768 @60Hz
215
720p @60Hz
204
1360x768 @60Hz
216
1080i @60Hz
205
1280x720 @60Hz
217
1080p @60Hz
206
1280x800 @60Hz
218
576p @50Hz
207
1280x1024 @60Hz
219
720p @50Hz
208
1440x900 @60Hz
220
1080i @50Hz
209
1400x1050 @60Hz
221
1080p @50Hz
210
1680x1050 @60Hz
222
NATIVE OUT1
211
1600x1200 @60Hz
223
NATIVE OUT2
