ASUS Z97-PRO GAMER
1-9
DDR3 3000 (O.C.) MHz capability
Vendors Part No. Size SS/DS Chip
Brand
Chip
NO.
Timing Voltage DIMM socket support
(Optional)
2 DIMMs 4 DIMMs
AVEXIR AVD3UH30001204G-4BZ1(XMP) 16GB(4x4GB) SS - - 12-14-14-35 1.65V • •
G.SKILL F3-3000C12Q-16GTXDG(XMP) 16GB(4x4GB) SS - - 12-14-14-35 1.65V • •
G.SKILL F3-3000C12D-8GTXDG(XMP) 8GB(2x4GB) SS - - 12-14-14-35 1.65V • •
CORSAIR CMY8GX3M2A3000C12R(XMP) 8GB(2x4GB) SS - - 12-14-14-36 1.65V •
DDR3 2933 (O.C.) MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
AVEXIR AVD3UH29331204G-4CI(XMP) 16GB(4x4GB) SS - - 12-14-14-35 1.65V • •
GEIL GPW38GB2933C12ADC(XMP) 8GB(2x4GB) SS - - 12-14-14-36 1.65V • •
APACER 78.BAGHB.AFL0C(XMP) 8GB(2x4GB) SS - - 12-14-14-35 1.65V • •
A_DATA AX3U2933W4G12(XMP) 16GB(4x4GB) SS - - 12-14-14-36 1.65V • •
G.SKILL F3-2933C12D-8GTXDG(XMP) 8GB(2x4GB) SS - - 12-14-14-35 1.65V • •
G.SKILL F3-2933C12Q-16GTXDG(XMP) 16GB(4x4GB) SS - - 12-14-14-35 1.65V • •
CORSAIR CMY16GX3M4A2933C12R(XMP) 16GB(4x4GB) SS - - 12-14-14-36 1.65V • •
DDR3 2800 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support (Optional)
2 DIMMs 4 DIMMs
AVEXIR
AVD3UH28001208G-
4BZ1(XMP)
32GB(4x8GB) DS - - 12-14-14-35 1.65V • •
A_DATA AX3U2800W4G12(XMP) 16GB(4x4GB) SS - - 12-14-14-36 1.65V • •
A_DATA AX3U2800W8G12(XMP) 32GB(4x8GB) DS - - 12-14-14-36 1.65V •
G.SKILL F3-2800C12Q-32GTXD(XMP) 32GB(4x8GB) DS - - 12-13-13-35 1.65V • •
G.SKILL F3-2800C12Q-32GTXDG(XMP) 32GB(4x8GB) DS - - 12-14-14-35 1.65V • •
G.SKILL F3-2800C11Q-16GTXD(XMP) 16GB(4x4GB) DS - - 11-13-13-35 1.65V • •
G.SKILL F3-2800C11D-8GTXD(XMP) 8GB(2x4GB) DS - - 11-13-13-35 1.65V • •
G.SKILL F3-2800C11D-8GTXDG(XMP) 8GB(2x4GB) DS - - 11-14-14-35 1.65V • •
G.SKILL F3-2800C11Q-16GTXDG(XMP) 16GB(4x4GB) DS - - 11-14-14-35 1.65V • •
G.SKILL F3-2800C10D-8GTXD(XMP) 8GB(2x4GB) DS - - 10-12-12-35 1.65V • •
G.SKILL F3-2800C12Q-16GTXDG(XMP) 16GB(4x4GB) DS - - 12-14-14-35 1.65V • •
G.SKILL F3-2800C11D-16GTXDG(XMP) 16GB(2x8GB) DS - - 11-14-14-35 1.65V • •
G.SKILL F3-2800C11Q-32GTXDG(XMP) 32GB(4x8GB) DS - - 11-14-14-35 1.65V • •
G.SKILL F3-2800C11D-16GTXD(XMP) 16GB(2x8GB) DS - - 11-13-13-35 1.65V • •
G.SKILL F3-2800C11Q-32GTXD(XMP) 32GB(4x8GB) DS - - 11-13-13-35 1.65V • •
G.SKILL F3-2800C12D-16GTXD(XMP) 16GB(2x8GB) DS - - 12-14-14-35 1.65V • •
APACER 78.BAGH5.AFD0C(XMP) 8GB(2x4GB) DS - - 12-14-14-35 1.65V •
APACER 78.CAGH6.AFD0C(XMP) 16GB(2x8GB) DS - - 12-14-14-35 1.65V •
CORSAIR CMD16GX3M4A2800C11(XMP) 16GB(4x4GB) DS - - 11-14-14-35 1.65V • •
CORSAIR CMD16GX3M4A2800C12(XMP) 16GB(4x4GB) DS - - 12-14-14-36 1.65V • •
CORSAIR CMY16GX3M4A2800C12R(XMP) 16GB(4x4GB) SS - - 12-14-14-36 1.65V • •
KINGSTON KHX28C12T2K2/8X 8GB(2x4GB) SS - - 12-14-14-32 1.65V • •
Team TXD38G2800HC12DBK(XMP) 32GB(4x8GB) DS - - 11-14-14-35 1.65V • •
