ASUS Z97-PRO GAMER
1-15
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
Crucial
BLS4G3D1609DS1S00.16FMR
(XMP)
4GB DS - - 9-9-9-24 1.5 • • •
Crucial
BLT4G3D1608DT1TX0.16FM
(XMP)
4GB DS - - 8-8-8-24 1.5 • • •
Elixir M2X2G64CB88G7N-DG(XMP) 2GB SS Elixir N2CB2G80GN-DG 9-9-9-28 - • • •
Elixir M2X4G64CB8HG5N-DG(XMP) 4GB DS Elixir N2CB2G80GN-DG 9-9-9-28 - • • •
G.SKILL F3-12800CL9D-8GBSR2(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.25 • • •
G.SKILL F3-12800CL9Q-16GBXL(XMP)
16GB(
4x4GB)
DS - - 9-9-9-24 1.5 • • •
G.Skill F3-12800CL9Q-16GBZL(XMP)
16GB(
4x4GB)
DS - - 9-9-9-24 1.5 • • •
G.SKILL F3-1600C9Q-32GXM(XMP)
32GB(
4x8GB)
DS - - - 1.5 • • •
GEIL GUP34GB1600C7DC(XMP)
4GB(2x
2GB)
DS - - 7-7-7-24 1.6 • • •
KINGMAX FLGE85F-C8KL9A(XMP) 2GB SS KINGMAX N/A 9-9-9-28 - • • •
KINGMAX FLGF65F-C8KL9A(XMP) 4GB DS KINGMAX N/A 9-9-9-28 - • • •
KINGSTON KHX16009CD3K2/8GX(XMP)
8GB(2x
4GB)
DS - - 9-9-9-27 1.65 • • •
KINGSTON KHX1600C9D3B1/4G(XMP) 4GB SS - - 9-9-9-27 1.65 • • •
KINGSTON KHX1600C9D3K3/12GX(XMP)
12GB(
3x4GB)
DS - - 9 1.65 • •
KINGSTON KHX1600C9D3K3/6GX(XMP)
6GB(3x
2GB)
DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3K3/6GX(XMP)
6GB(3x
2GB)
DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3K4/16GX(XMP)
16GB(
4x4GB)
DS - - 9-9-9-24 1.65 • • •
KINGSTON KHX1600C9D3K6/24GX(XMP)
24GB(
6x4GB)
DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3LK2/8GX(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.35 • • •
KINGSTON KHX1600C9D3P1K2/8G
8GB(2x
4GB)
DS - - 9 1.5 • • •
KINGSTON KHX16C10B1K2/16X(XMP)
16GB(
2x8GB)
DS - - - 1.5 • • •
KINGSTON KHX16C9K2/16
16GB(
2x8GB)
DS - -
1333-9-9-
9-24
1.5 • • •
KINGSTON KHX16C9P1K2/16
16GB(
2x8GB)
DS - - - 1.5 • • •
KINGSTON KVR16N11/4 4GB DS KINGSTON D2568JPUCPGGBU
11-11-11-
28-1
- • • •
KINGSTON KVR16N11/4 4G DS Hynix H5TQ2G83CFRPBC - 1.5 • • •
Micron MT16JTF1G64AZ-1G6E1 8GB DS Micron D9QBJ - - • • •
Micron MT8JTF51264AZ-1G6E1 4GB SS Micron D9QBJ - - • • •
MICRON MT8KTF25664AZ-1G6M1 2GB SS MICRON D9PFJ - - • • •
Patriot PV316G160C9K(XMP)
16GB(
2x4GB)
SS - - 9-9-9-24 1.5 • • •
Patriot PV316G160C9K(XMP)
16GB(
2x8GB)
SS - - 9-9-9-24 1.5 • • •
SanMax SMD-4G28N1P-16KM 4GB SS ELPIDA J4208BBBG-GN-F 1600 - • • •
SanMax SMD-4G68HP-16KZ 4GB DS Hynix H5TQ2G83BFRPBC - 1.5 • • •
SanMax SMD-4G68NG-16KK 4GB DS ELPIDA J2108BDBG-GN-F - - • • •
SanMax SMD-8G28NP-16KM 8GB DS ELPIDA J4208BBBG-GN-F 1600 - • • •
Silicon
Power
SP002GBLTU160V02(XMP) 2GB SS S-POWER 20YT5NG 9-11-11-28 1.5 • • •
DDR3 1600 MHz capability
DDR3 1333 MHz capability
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
Silicon
Power
SP004GBLTU160V02(XMP) 4GB DS S-POWER 20YT5NG 9-9-9-24 1.5 • • •
Silicon
Power
SP004GXLYU160NSA(XMP) 4GB SS - - 9-9-9-27 - • • •
Silicon
Power
SP008GXLYU160NSA(XMP) 8GB DS - - 9-9-9-27 - • • •
Team TED34GM1600C11BK 4GB DS Hynix H5TC2G83EFR 11-11-11-28 1.5 • • •
Team TED38GM1600C11BK 8GB DS Hynix H5TQ4G83AFR 11-11-11-28 1.5 • • •
Team TLD34G1600HC9BK(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
Team TLD38G1600HC9BK(XMP)
16GB(
2x8GB)
DS - - 9-9-9-24 1.5 • • •
Team TXD34096M1600HC9-D(XMP) 4GB DS Hynix H5TC2G83BFRH9A 9-9-9-24 1.5 • • •
Transcend TS1GLK64V6H(620945) 8GB DS SAMSUNG K4B4G0846B - - • • •
Transcend TS1GLK64W6H 8GB DS SAMSUNG K4B4G0846B
11-11-11-
28-1
- • • •
Transcend TS512MLK64W6H 4GB SS SAMSUNG K4B4G0846B
11-11-11-
28-2
- • • •
UMAX 84E44G93UM-16BPSYW 4GB SS UMAX U2S96D30TP-16 11-11-11-28 - • • •
UMAX 84E48G93UM-16BPSYW 8GB DS UMAX U2S96D30TP-16 11-11-11-28 - • • •
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
AMD AE32G1339U1-U 2GB SS AMD 23EY4587MB3H - 1.5 • • •
AMD AE34G1339U2-U 4GB DS AMD 23EY4587MB3H - 1.5 • • •
Apacer 78.B1GDE.9L10C 4GB DS Apacer AM5D5908CEHSBG 9 - • • •
Asint SLA302G08-EDJ1C 2GB SS ASint 302G08-DJ1C - - • • •
Asint SLA304G08-EDJ1B 4GB SS Asint 304G08-DJ1B 9-10-10-26 - • • •
Asint SLB304G08-EDJ1B 8GB DS Asint 304G08-DJ1B 9-9-9-24 - • • •
BUFFALO D3U1333-1G 1GB SS Elpida J1108BFBG-DJ-F - - • • •
BUFFALO D3U1333-2G 2GB DS Elpida J1108BFBG-DJ-F - • • •
BUFFALO D3U1333-4G 4GB DS NANYA NT5CB256M8BN-CG - • • •
CORSAIR CMV8GX3M1A1333C9 8GB DS - - 9-9-9-24 - • • •
CORSAIR CMV8GX3M2A1333C9
8GB(2x
4GB)
DS - N/A 9-9-9-24 - • • •
CORSAIR
CMX4GX3M1A1333C9
(Ver2.12)
4GB(1x
4GB)
DS - - 9-9-9-24 1.5 • •
CORSAIR
CMX4GX3M1A1333C9
(Ver5.11)
4GB(1x
4GB)
DS - - 9-9-9-24 1.5 • •
CORSAIR
CMX8GX3M1A1333C9
(Ver2.2)
8GB DS - - 9-9-9-24 1.5 • •
CORSAIR CMX8GX3M2A1333C9(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
G.SKILL F3-10666CL9D-8GBXL
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
GEIL GG34GB1333C9DC
4GB(2x
2GB)
DS GEIL GL1L128M88BA15B 9-9-9-24 1.3 • • •
GEIL GVP34GB1333C9DC
4GB(2x
2GB)
DS - - 9-9-9-24 1.5 • • •
GEIL GVP38GB1333C9DC
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
(continuedonthenextpage)
