ASUS Z97-PRO GAMER
1-11
DDR3 2133 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
AEXEA AXA3ES4GK2000LG28V(XMP) 4GB(2x2GB) DS - - - 1.65V • • •
Asint SLA302G08-ML2HB(XMP) 4GB DS Hynix
H5TQ2G83
BFRH9C
9-9-9-27 - • • •
GEIL GUP34GB2000C9DC(XMP) 4GB(2x2GB) DS - - 9-9-9-28 1.65V • • •
DDR3 2000 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
A-DATA AX3U2133W4G10-DR(XMP) 8GB(2x4GB) SS - - 10-11-11-30 1.65V • • •
A-DATA AX3U2133W8G10-DR(XMP) 16GB(2x8GB) DS - - 10-11-11-30 1.65V • • •
Apacer 78.BAGE4.AFD0C(XMP) 8GB(2x4GB) DS - - 9-9-9-24 - • • •
Apacer AHU04GFB33CAQ3R(XMP) 4GB DS - - 11-13-13-31 - • • •
CORSAIR
CMD16GX3M2A2133C9(Ver4.21)
(XMP)
16GB(2x8GB) DS - - 9-11-11-31 1.65V • • •
CORSAIR
CMD32GX3M4A2133C9(Ver4.21)
(XMP)
32GB(4x8GB) DS - - 9-11-11-31 1.65V • • •
CORSAIR
CMD8GX3M2A2133C9(Ver1.5)
(XMP)
8GB(2x4GB) DS - - 9-11-10-27 1.5V • •
CORSAIR
CMD8GX3M2B2133C9(Ver5.12)
(XMP)
8GB(2x4GB) DS - - 9-11-11-31 1.65V • • •
CORSAIR
CMY8GX3M2A2133C11R(Ver4.21)
(XMP)
8GB(2x4GB) DS - - 11-11-11-27 1.5V • • •
CORSAIR
CMZ8GX3M2A2133C11R(Ver4.21)
(XMP)
8GB(2x4GB) DS - - 11-11-11-27 1.5V • • •
G.SKILL F3-17000CL11Q2-64GBZLD(XMP) 64GB(8x8GB) DS - - 11-11-11-30 1.5V • • •
G.SKILL F3-17000CL9Q-16GBZH(XMP) 16GB(4x4GB) DS - - 9-11-10-28 1.65V • • •
G.SKILL F3-2133C10Q-32GSR(XMP) 32GB(4x8GB) DS - - 10-12-12-31 1.5V • • •
G.SKILL F3-2133C11Q-32GZL(XMP) 32GB(4x8GB) DS - - 11-11-11-31 1.5V • • •
KINGSTON KHX2133C11D3K4/16GX(XMP) 16GB(4x4GB) DS - - 11-12-11-30 1.65V • • •
KINGSTON KHX21C11T3FK8/64X(XMP) 64GB(8x8GB) DS - - 9-9-9-24 1.5V • • •
Silicon
Power
SP004GXLYU213NSA(XMP) 4GB SS - - 11-12-11-30 - • • •
Silicon
Power
SP008GXLYU213NSA(XMP) 8GB DS - - 11-12-11-30 - • • •
Transcend TX2133KLH-16GK(XMP) 16GB(2x8GB) DS - - 10-11-10-27 1.6V • • •
Transcend TX2133KLN-8GK(XMP) 8GB(2x4GB) DS - - 10-11-10-27 1.6V • • •
