ASUS Z97-PRO GAMER

2-29

SVID Voltage Override [Auto]

This item allows you to set the SVID Voltage override. By default, this item takes the standard

value of the installed CPU. You can use the <+> or <-> keys to adjust the value. The values

range from 0.001V to 2.440 V with a 0.001 V interval.

2.5.23 CPU Input Voltage [Auto]

Allows you to set the input voltage for the CPU by the external voltage regulator. You can

use the <+> or <-> keys to adjust the value. The values range from 0.800V to 2.700V with a

0.010V interval.

2.5.24 DRAM Voltage [Auto]

Allows you to set the DRAM Voltage. You can use the <+> or <-> keys to adjust the value.

The values range from 1.20000V to 1.92000V with a 0.01000V interval.

According to Intel CPU specications, DIMMs with voltage requirement over 1.65V may

damage the CPU permanently. We recommend that you install the DIMMs with the voltage

requirement below 1.65V.

2.5.25 PCH VLX Voltage [Auto]

This item allows you to set the I/O voltage on the PCH (Platform Controller Hub). You can

use the <+> or <-> keys to adjust the value. The values range from 1.20000V to 2.00000V

with a 0.01250V interval.

2.5.26 PCH Core Voltage [Auto]

This item allows you to set the core voltage on the PCH (Platform Controller Hub). You can

use the <+> or <-> keys to adjust the value. The values range from 0.70000V to 1.50000V

with a 0.01250V interval.

The system may need better cooling system for a more stable performance under high

voltage settings.

2.5.27 DRAM CTRL REF Voltage [Auto]

This item allows you to set the DRAM reference voltage on the control lines from the memory

bus. You can use the <+> or <-> keys to adjust the value. The values range from 0.39500V to

0.63000V with a 0.00500V interval.

2.5.28 DRAM DATA REF Voltage on CHA/CHB [Auto]

This item allows you to set the DRAM reference voltage on the data lines on Channels A and

B. You can use the <+> or <-> keys to adjust the value. The values range from 0.39500V to

0.63000V with a 0.00500V interval.

To set a value for the DRAM reference voltage, we recommend you to set a value close to

the standard value which is 0.500000x.

2.5.29 CPU Spread Spectrum [Auto]

This item allows you to enhance the BCLK overclocking capability or reduce the EMI

(electromagnetic disturbance) generated by the BCLK. Set this item to [Enabled] for EMI

reduction, or set this item to [Disabled] to enhance BCLK overclocking. Conguration options:

[Auto] [Disabled] [Enabled]
