Chapter 1: Product introduction
DDR3 1866 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
CORSAIR
CMD16GX3M2A1866C9(Ver5.29)
(XMP)
16GB(2x8GB) DS - - 9-9-9-27 1.5 • •
CORSAIR
CMD16GX3M4A1866C9(Ver4.13)
(XMP)
16GB(4x4GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMD16GX3M4A1866C9(Ver8.16)
(XMP)
16GB(4x4GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMD32GX3M4A1866C9(Ver3.24)
(XMP)
32GB(4x8GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMD8GX3M2A1866C9(Ver4.13)
(XMP)
8GB(2x4GB) DS - - - 1.5 • • •
CORSAIR
CMD8GX3M2A1866C9(Ver5.12)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR
CMD8GX3M2A1866C9(Ver8.16)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR
CMT32GX3M4X1866C9(Ver3.23)
(XMP)
32GB(4x8GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMY16GX3M2A1866C9(Ver4.21)
(XMP)
16GB(2x8GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMY8GX3M2A1866C9(Ver3.24)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMZ16GX3M2A1866C10(Ver5.29)
(XMP)
16GB(2x8GB) DS - - 10-11-10-30 1.5 • • •
CORSAIR CMZ16GX3M2A1866C9(XMP) 16GB(2x8GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR
CMZ32GX3M4X1866C10(Ver3.23)
(XMP)
32GB(4x8GB) DS - - 10-11-10-27 1.5 • • •
CORSAIR
CMZ32GX3M4X1866C10(Ver3.23)
(XMP)
32GB(4x8GB) DS - - 10-11-10-27 1.5 • • •
CORSAIR
CMZ8GX3M2A1866C9(Ver8.16)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMZ8GX3M2A1866C9(XMP) 8GB(2x4GB) DS - - 9-10-9-27 1.5 • •
CORSAIR
CMZ8GX3M2A1866C9G(Ver5.12)
(XMP)
8GB(2x4GB) DS - - 9-10-9-27 1.5 • • •
Cricial BLE8G3D1869DE1TX0.16FED(XMP) 16GB(2x8GB) DS - - 9-9-9-27 1.5 • • •
Crucial BLE4G3D1869DE1XT0.16FMD(XMP) 4GB DS - - 9-9-9-27 1.5 • • •
G.SKILL F3-14900CL10Q-32GBZL(XMP) 32GB(4x8GB) DS - - 10-11-10-30 1.5 • • •
G.SKILL F3-14900CL9D-8GBSR(XMP) 8GB(2x4GB) DS - - 9-10-9-28 1.5 • • •
G.SKILL F3-14900CL9Q-16GBXL(XMP) 16GB(4x4GB) DS - - 9-10-9-28 1.5 • • •
G.SKILL F3-14900CL9Q-16GBZL(XMP) 16GB(4x4GB) DS - - 9-10-9-28 1.5 • • •
G.SKILL F3-14900CL9Q-16GBZL(XMP) 16GB(4x4GB) DS - - 9-10-9-28 1.5 • • •
G.SKILL F3-1866C10Q2-64GZM(XMP) 64GB(2x8GB) DS - - 10-11-10-30 1.5 • • •
G.SKILL F3-1866C10Q2-64GZM(XMP) 64GB(2x8GB) DS - - 10-11-10-30 1.5 • • •
G.SKILL F3-1866C9Q-32GXM(XMP) 32GB(4x8GB) DS - - 9-10-9-28 1.5 • • •
GEIL GEEL316GB1866C9DC(XMP) 16GB(2x8GB) DS - - 9-10-9-28 1.65 • • •
KINGSTON KHX1866C9D3K2/8GX(XMP) 8GB(2x4GB) DS - - - 1.65 • • •
Silicon
Power
SP004GXLYU186NSA(XMP) 4GB SS - - 9-11-9-27 - • • •
Silicon
Power
SP008GXLYU186NSA(XMP) 8GB DS - - 9-11-9-27 - • • •
