Asus z97-pro gamer [23/102] Ddr3 1600 mhz capability
![Asus z97-pro gamer [23/102] Ddr3 1600 mhz capability](/views2/1161715/page23/bg17.png)
ASUS Z97-PRO GAMER
1-13
DDR3 1600 MHz capability
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
A-DATA AD3U1600W4G11 4GB SS A-DATA 3WCD-1211A 11-11-11-28 - • • •
A-DATA AD3U1600W8G11 8GB DS A-DATA 3WCD-1211A 11-11-11-28 - • • •
A-DATA ADDU1600W4G11-B 4GB SS A-DATA DWND-1211A 9-9-9-24 - • • •
A-DATA ADDU1600W8G11-B 8GB DS ELPIDA J4208EBBG-GN-F 9-9-9-24 - • • •
A-DATA AX3U1600W4G9-DB(XMP)
8GB(2x
4GB)
SS - - 9-9-9-24 1.5 • • •
A-DATA AX3U1600W8G9-DB(XMP)
16GB(2x
8GB)
DS - - 9-9-9-24 1.5 • • •
AMD AE32G1609U1-U 2GB SS AMD 23EY4587MB6H - 1.5 • • •
AMD AE34G1609U2-U 4GB DS AMD 23EY4587MB6H - 1.5 • • •
AMD AP38G1608U2K(XMP)
8GB(2x
4GB)
DS - - 9-9-9-28 1.65 • • •
Apacer 78.B1GE3.9L10C 4GB DS Apacer AM5D5908DEQSCK - 1.65 • • •
Apacer 78.B1GET.9K00C 4GB SS Apacer AM5D6008BQQSCK 11-11-11-28 - • • •
Apacer 78.C1GET.9K10C 8GB DS Apacer AM5D6008BQQSCK 11-11-11-31 - • • •
Apacer AHU04GFA60C9Q3R(XMP) 4GB DS - - 11-11-11-28 - • • •
Apacer AHU08GFA60CBT3R(XMP) 8GB DS - - 9-9-9-24 - • •
Asint SLA302G08-EGG1C(XMP) 4GB DS Asint 302G08-GG1C 9-9-9-27 - • • •
Asint SLA302G08-EGJ1C(XMP) 4GB DS Asint 302G08-GJ1C 9-9-9-27 - • • •
Asint SLA302G08-EGN1C 4GB DS ASint 302G08-GN1C - - • • •
Asint SLA304G08-ENG1B 4GB SS Asint 304G08-GN1B 9-11-11-28 - • • •
Asint SLB304G08-EGJ1B(XMP) 8GB DS - - 9-9-9-27 - • • •
Asint SLB304G08-EGN1B 8GB DS ASint 304G08-GN1B - - • • •
Asint SLZ302G08-EGN1C 2GB SS ASint 302G08-GN1C - - • • •
AVEXIR AVD3U16000904G-2CW(XMP)
8GB(2x
4GB)
DS - - 11-11-11-28 1.5 • • •
CORSAIR
CMD16GX3M2A1600C9(Ver8.21)
(XMP)
16GB(
2x8GB)
DS - - 9-9-9-24 1.5 • •
CORSAIR
CMD8GX3M2A1600C8(Ver5.12)
(XMP)
8GB(2x
4GB)
DS - -
16008-8-
8-24
1.5 • • •
CORSAIR
CMD8GX3M2A1600C9(Ver2.12)
(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
CORSAIR
CML16GX3M2A1600C10(Ver2.21)
(XMP)
16GB(
2x8GB)
DS - - 10-10-10-27 1.5 • • •
CORSAIR
CML8GX3M2A1600C9(Ver7.12)
(XMP)
8GB(2x
4GB)
DS - - 9-9-9-24 1.5 • • •
CORSAIR CMV8GX3M1A1600C11 8GB DS - - 11-11-11-30 - • • •
CORSAIR
CMX8GX3M2A1600C9(Ver3.19)
(XMP)
8GB(2x
4GB)
SS - - 9-9-9-24 1.65 • • •
CORSAIR
CMZ16GX3M2A1600C10
(Ver.3.24)(XMP)
16GB(
2x8GB)
DS - - 10-10-10-27 1.5 • • •
CORSAIR CMZ16GX3M4A1600C9(XMP)
16GB(
4x4GB)
DS - - 9-9-9-24 1.5 • • •
CORSAIR
CMZ16GX3M4X1600C9(Ver8.16)
(XMP)
16GB(
4x4GB)
DS - - 9-9-9-24 1.5 • • •
CORSAIR
CMZ32GX3M4X1600C10(Ver2.2)
(XMP)
32GB(
4x8GB)
DS - - 10-10-10-27 1.5 • • •
CORSAIR
CMZ4GX3M1A1600C9(Ver8.16)
(XMP)
4GB(1x
4GB)
DS - - 9-9-9-24 1.5 • •
CORSAIR
CMZ8GX3M1A1600C10(Ver3.23)
(XMP)
8GB(1x
8GB)
DS - - 10-10-10-27 1.5 • •
CORSAIR
CMZ8GX3M1A1600C10(Ver8.21)
(XMP)
8GB(1x
8GB)
DS - - 10-10-10-27 1.5 • •
CORSAIR CMZ8GX3M2A1600C8(XMP)
8GB(2x
4GB)
DS - - 8-8-8-24 1.5 • • •
