ASUS Z97-PRO GAMER
2-43
CPU Fan Min. Duty Cycle(%) [60]
Use the <+> or <-> keys to adjust the minimum CPU fan duty cycle. The values range
from 20% to 100%. When the CPU temperature is under 20°C, the CPU fan operates
at the minimum duty cycle.
2.7.6 Chassis Fan 1/ Chassis Fan 2 / Chassis Fan 3 Q-Fan
Control [DC Mode]
[Disabled] Disables the chassis Q-Fan control feature.
[PWM Mode] Enable the chassis Q-Fan control in PWM mode for 4-pin chassis fan.
[DC Mode] Enable the chassis Q-Fan control in DC mode for 3-pin chassis fan.
The following items appear only when you set Chassis Fan 1/ Chassis Fan 2 / Chassis
Fan 3 Q-Fan Control to [PWM Mode] or [DC Mode].
Chassis Fan 1/ Chassis Fan 2/ Chassis Fan 3 Q-Fan Source [CPU]
This item allows you to control the assigned fan according to the selected temperature
source. When select T_SENSOR, plug a thermistor cable to T_SENSOR header and stick
it to the desired component as the temperature source. Conguration options: [CPU] [MB]
[VRM] [PCH CORE] [T_SENSOR]
Chassis Fan 1/ Chassis Fan 2/ Chassis Fan 3 Speed Low Limit [300 RPM]
This item appears only when you enable the Chassis Fan Q-Fan Control feature and allows
you to disable or set the chassis fan warning speed. Conguration options: [Ignore] [200RPM]
[300 RPM] [400 RPM] [500 RPM] [600 RPM]
Chassis Fan 1/ Chassis Fan 2/ Chassis Fan 3 Prole [Standard]
This item appears only when you enable the Chassis Fan 1/2/3/4 Q-Fan Control feature and
allows you to set the appropriate performance level of the chassis fan 1/2/3/4.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust depending
on the chassis temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan operation.
[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.
[Manual] Sets to [Manual] to assign detailed fan speed control parameters.
The following four items appear only when you set Chassis Fan 1/2/3 Prole to [Manual].
Chassis Fan 1/2/3 Upper Temperature [70]
Use the <+> or <-> keys to adjust the upper limit of the chassis temperature. The
values range from 45°C to 75°C.
Chassis Fan 1/2/3 Max. Duty Cycle(%) [100]
Use the <+> or <-> keys to adjust the maximum chassis fan duty cycle. The values
range from 60% to 100%. When the chassis temperature reaches the upper limit, the
chassis fan will operate at the maximum duty cycle.
