Chapter 1: Product introduction
DDR3 2666 (O.C.) MHz capability
Vendors Part No. Size SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
Apacer 78.BAGFF.AFC0C(XMP) 8GB(2x4GB) DS - - 12-13-13-35 - • • •
Apacer 78.BAGFR.AFD0C(XMP) 8GB(2x4GB) DS - - 12-13-13-35 - • • •
Apacer 78.CAGFF.AFD0C(XMP) 16GB(2x8GB) DS - - 12-13-13-35 - • • •
CORSAIR CMD16GX3M4A2666C11
(Ver5.12)(XMP)
16GB(4x4GB) DS - - 11-13-13-35 1.65V • • •
G.SKILL F3-2666CL10Q-
16GBZHD(XMP)
16GB(4x4GB) DS - - 10-12-12-31 1.65V • • •
GEIL GOC332GB2666C11
QC(XMP)
32GB(4x8GB) DS - - 11-13-13-32 1.65V • • •
KINGSTON KHX26C11T2K2/8X(XMP) 8GB(2x4GB) SS - - 11-13-13-32 1.65V • •
DDR3 2400 (O.C.) MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
A-DATA AX3U2400W4G11-DMV(XMP) 8GB(2x4GB) SS - - 11-13-13-35 1.65V • • •
A-DATA AX3U2400W8G11-DMV(XMP) 16GB(2x8GB) DS - - 11-13-13-35 1.65V • • •
Apacer 78.BAGFL.AFD0C(XMP) 8GB(2x4GB) DS - - 11-12-12-30 - • • •
Apacer 783BAGF3.AFD0C(XMP) 8GB(2x4GB) DS - - 11-11-11-30 - • • •
CORSAIR
CMD16GX3M2A2400C10(Ver4.21)
(XMP)
16GB(2x8GB) DS - - 10-12-12-31 1.65V • • •
CORSAIR
CMD32GX3M4A2400C10(Ver5.29)
(XMP)
32GB(4x8GB) DS - - 10-12-12-31 1.65V • •
CORSAIR
CMY16GX3M2A2400C10A(Ver4.21)
(XMP)
16GB(8x2GB) DS - - 10-12-12-31 1.65V • • •
CORSAIR
CMY16GX3M2A2400C10R(Ver4.21)
(XMP)
16GB(2x8GB) DS - - 10-12-12-31 1.65V • • •
CORSAIR CMZ16GX3M2A2400C10(Ver4.21) 16GB(2x8GB) DS - - 10-12-12-31 1.65V • • •
G.SKILL F3-19200CL10Q2-64GBZHD(XMP) 64GB(8x8GB) DS - - 10-12-12-31 1.65V • • •
G.SKILL F3-19200CL10Q-32GBZHD(XMP) 32GB(4x8GB) DS - - 10-12-12-31 1.65V • •
G.SKILL F3-19200CL11Q-16GBZHD(XMP) 16GB(4x4GB) DS - - 11-11-11-31 1.65V • • •
G.SKILL F3-19200CL9D-4GBPIS(XMP) 4G(2x2G) DS - - 9-11-9-28 1.65V • •
G.SKILL F3-19200CL9Q-16GBZMD(XMP) 16GB(4x4GB) DS - - 9-11-11-31 1.65V • • •
G.SKILL F3-2400C11Q-32GXM(XMP) 32GB(4x8GB) DS - - 11-13-13-31 1.65V • • •
GEIL GOC316GB2400C10QC(XMP) 16GB(4x4GB) DS - - 10-11-11-30 1.65V • • •
GEIL GOC316GB2400C11QC(XMP) 16GB(4x4GB) DS - - 11-11-11-30 1.65V • • •
Kingston KHX2400C11D3K4/8GX(XMP) 8GB(4x2GB) SS - - 11-13-11-30 1.65V • • •
KINGSTON KHX24C11K4/16X(XMP) 16GB(4x4GB) DS - - 11-13-13-30 1.65V • • •
KINGSTON KHX24C11T2K2/8X(XMP) 8GB(2x4GB) DS - - - 1.65V • • •
KINGSTON KHX24C11T3K2/16X(XMP) 16GB(2x8GB) DS - - 11-13-13-32 1.65V • •
KINGSTON KHX24C11T3K4(XMP) 16GB(4x4GB) DS - - 11-13-13-30 1.65V • • •
KINGSTON KHX24C11T3K4/32X(XMP) 32GB(4x8GB) DS - - 9-9-9-24 1.65V • • •
Mushkin 997122R(XMP) 16GB(2x8GB) DS - - 10-12-12-28 1.65V • • •
Silicon
Power
SP004GXLYU240NSA(XMP) 4GB SS - - 11-13-13-32 - • • •
Transcend TX2400KLN-8GK(XMP) 8GB(2x4GB) DS - - 11-12-11-29 1.6V • • •
