ASUS Z97-PRO GAMER
2-11
2.2.3 QFan Control
The QFan Control allows you to set a fan prole or manually congure the operating speed of
your CPU and chassis fans.
Click to select a fan to be
congured
Click to activate
PWM Mode
Click to undo the
changes
Click to apply the
fan setting
Click to go
back to main
menu
Select a prole to apply to
your fans
Click to activate DC Mode
