Asus z97-pro gamer [9/102] Z97 pro gamer specifications summary
![Asus z97-pro gamer [9/102] Z97 pro gamer specifications summary](/views2/1161715/page9/bg9.png)
ix
Specications are subject to change without notice.
Z97-PRO GAMER specications summary
Internal
connectors
1 x 19-pin USB 3.0 / 2.0 connector support additional 2 USB 3.0 / 2.0 ports
3 x USB 2.0 / 1.1 connectors support additional 6 USB 2.0 / 1.1 ports
1 x System panel connector
1 x S/PDIF out header
1 x Front panel audio connector (AAFP)
4 x SATA 6.0 Gb/s connectors (gray)
1 x M.2 Socket 3 for M Key, type 2260/2280 devices
1 x SATA Express connector, compatible with 2 x SATA 6.0 Gb/s ports
1 x 4-pin CPU fan connector
1 x 4-pin CPU optional fan connector
3 x Chassis fan connectors (4-pin) for both 3-pin (DC mode) and 4-pin (PWM
mode) coolers control
1 x Thermal sensor connector
1 x COM header
1 x TPM header
1 x Clear CMOS jumper
1 x 24-pin EATX power connector
1 x 8-pin ATX 12V power connector
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM2.0, SM BIOS 2.8,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note,
Last Modied Log, F12 PrintScreen function, F3 Shortcut function, and ASUS
DRAM SPD (Serial Presence Detect) memory information
Manageability
WfM 2.0, DMI 2.7, WOL by PME, PXE
Support DVD
Drivers
ASUS utilities
EZ Update
Anti-virus software (OEM version)
OS support
Windows
®
8.1, Windows
®
8, Windows
®
7
Form factor
ATX form factor: 12.0 in. x 9.6 in. (30.5 cm x 24.4 cm)
