2-11
ASUS TS700-E8-PS4, TS700-E8-RS8
Dual CPU configuration
YoucanrefertothefollowingrecommendedmemorypopulationforadualCPUconguration.
Single CPU configuration
YoucanrefertothefollowingrecommendedmemorypopulationforasingleCPUconguration.
Dual CPU configuration
DIMM (CPU1) DIMM (CPU2)
A2 A1 B2 B1 C2 C1 D2 D1
E2 E1 F2 F1 G2 G1 H2 H1
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
12 DIMMs
P P P P P P P P P P P P
16 DIMMs
P P P P P P P P P P P P P P P P
Single CPU configuration (must be installed on CPU1)
DIMM
A2 A1 B2 B1 C2 C1 D2 D1
1 DIMM
P
2 DIMMs
P P
4 DIMMs
P P P P
8 DIMMs
P P P P P P P P
