ASUS TS700-E8-PS4, TS700-E8-RS8
2.8.2 SATA/SAS backplane cabling
Thesystemcomeswithapre-installedSATA/SASbackplane.TheSATA/SASbackplane
hasfour22-pinSATA/SASconnectorstosupportSerialATAharddiskdrivesandSAShard
diskdrives.Thebackplanedesignincorporatesahot-swapfeaturetoalloweasyconnection
orremovalofSATA/SASharddisks.TheLEDsonthebackplaneconnecttothefrontpanel
LEDstoindicateHDDstatus.Seesection
1.7 LED information
for details.
Front side
ThefrontsideoftheSATA/SASbackplanefacesthefrontpanelwheninstalled.Thisside
includesfourSATA/SASconnectorsforthehot-swapdrivetrays.
EachSATA/SASconnectorislabeled(HDD1,HDD2,
HDD3,HDD4)soyoucaneasilydeterminetheir
counterpartconnectorsatthebacksideofthebackplane.
Refertothetableforreference.
Drive status LEDs
HDD1
HDD2
HDD3
HDD4
HDD1
HDD Device Front side connector Back side connector
HDD1 HDD1 CON1
HDD2 HDD2 CON2
HDD3 HDD3 CON3
HDD4 HDD4 CON4
