Chapter 2: Hardware setup
2-18
6. Pushthetrayleveruntilitclicks,and
secures the drive tray in place. The drive
tray is correctly placed when its front
edgealignswiththebayedge.
7. Repeatsteps1to6ifyouwishtoinstall
asecondSATA/SASdrive.
2.5.5 Installing a 2.5-inch hard disk drive (TS700-E8-RS8
only)
Thesystemcomeswithtwohot-swap2.5-inchharddiskdrivesontherearpanelformounting
SATA/SASorSSDharddiskdrives.
Toinstalla2.5-inchharddiskdrive:
1. Releaseadrivetraybypushingthe
spring lock to the right, and then
pulling the tray lever outward. The
drive tray ejects slightly after you pull
out the lever.
Support
beam
3. Placethedrivetrayonaatsurface.
4. Release the screws on each side of
the drive tray to release the drive tray
metalbeam.
5. Findtheharddiskdriveyouwantto
installanditsbundledscrews.
Whenthedrivetrayisout,itscaseisfacingdownwards.
2. Firmlyholdthetrayleverandpullthe
drivetrayoutofthebay.
