2-19
ASUS TS700-E8-PS4, TS700-E8-RS8
6. OrientandplacetheSSDintothetray.
EnsurethattheSSDisttedrmly
inside the drive tray and that the four
screws of the SSD matches the four
screws holes of the drive tray.
Wheninstalled,theSATA/SASconnectoronthedriveconnectstotheSATA/
SASinterfaceonthebackplane.
9. Repeatsteps1to8toinstallother2.5-inchharddiskdrives.
7. Carefully insert the drive tray with its
case facing downwards and push it
allthewaytothedrivebay.
8. Lockthesecuretabtosecurethe
drive tray in place.
Whenthedrivetrayassemblyisproperlyinstalled,youwillseetheedgeofthedrivetrayis
in align with the chassis cover.
