Chapter 2: Hardware setup
2-32
2.9.3 Chassis footpads
Thebareboneserversystemisshippedwithfourfootpadsattachedtothebottomofthe
chassisforstability.Youneedtoremovethesefootpadsifyouwishtoinstallthesystemto
arack.RefertoChapter3:Installationoptionsofthisuserguide,andtothe“RackmountKit”
user guide for instructions.
To remove the footpads:
1. Laythesystemchassisonitsside.
2. Removethefootpadbyrotatingit
counterclockwisewithaPhilips(cross)
screwdriver.
3. Repeat steps 1 and 2 to remove the
other three footpads.
