Chapter 2: Hardware setup
2-20
2.6 5.25-inch or 3.5-inch drives
Ensuretounplugthepowercablebeforeinstallingorremovinganysystemcomponents.
Failuretodosomaycausedamagetothemotherboardandothersystemcomponents!
Thesystemcomeswiththree5.25-inch
drivebayslocatedontheupperfrontpart
ofthechassis.Anopticaldrivethatcomes
standard with the system package occupies
theuppermostbay(labeled1).Thelowerbays
(labeled2and3)areavailableforadditional
5.25-inchdrivesor5.25-inchto3.5-inchhard
driveadapterforinstalling3.5-inchziporoppy
disk drives.
Youmustremovethefrontpanelassemblybeforeinstallinga5.25-inchdrive.
2.6.1 Installing a 5.25-inch drive
1. Unscrew and remove the metal cover of
thebaywhereyouwanttoinstallthe5.25-
inch drive.
2. Insertthedriveintothebayandslidethe
baylocktotherightuntilitclicksinplace.
3. ConnecttheSATAcabletotheSATA
connectoronthebackofthedrive.
4. Connect the 4-pin power connector from
the power supply to the power connector
onthebackofthedrive.
3
2
1
2
4
3
