Chapter 2: Hardware setup
2-16
2.5.3 Removing the backplane
DONOTremovethebackplaneunlessnecessary!
1. Removeallhot-swapHDDtraysfrom
the chassis.
2. DisconnectallcablesfromtheSATA/
SASbackplane.
3. Loosenthefourscrewsonthe
backplane.
4. Firmlyholdthebackplane,andturnitin
the direction of the arrow.
5. Removethebackplanefromthemodule.
2.5.4 Installing a hot-swap SATA/SAS hard disk drive
1. Releaseadrivetraybypushingthe
spring lock to the right, and then pulling
the tray lever outward. The drive tray
ejects slightly after you pull out the lever.
