Chapter 2: Hardware setup
2-30
Removing the rear system fan
To remove the rear system fan:
1. Squeezethefrontsystemfanlatches(stepa)andpulloutthefrontsystemfan(stepb),
asshowninthegurebelow.
2. UnplugthesystemfancablefromtheREAR_FAN1connectoronthemotherboard.
3. Carefully remove the system fan.
Followthepreviousinstructionsinreversetoreinstalltherearsystemfan.
a
a
b
