Asus tuf sabertooth z170 mark 1 [106/140] Chapter 4

4-8

Chapter 4: Software Support

Chapter 4

DIGI+ Power Control

ASUSDIGI+PowerControlfeaturestherevolutionaryandinnovativedigitalVRMandDRAM

Voltagecontrollers.Thesecontrollersoffersultra-precisememoryandvoltagetuningfor

optimalsystemefciency,stabilityandperformance.

DIGI+PowerControl - CPU

Click or tap to switch

between items

Click or tap to go back

to the previous screen

Click or tap to undo

the changes

Click or tap to apply

the changes

Click or tap to go the

CPU configurations

screen

Click or tap to go the

DRAM configurations

screen
