Asus tuf sabertooth z170 mark 1 [51/140] Chapter 1

SABERTOOTH Z170 MARK 1

1-35

Chapter 1

13. M.2 socket 3

This socket allows you to install an M.2 (NGFF) SSD module.

• This socket supports M Key and type 2242/2260/2280 storage devices.

• The M.2 Socket 3 shares bandwidth with PCIe x16_3 slot.

The M.2 (NGFF) SSD module is purchased separately.
