Asus tuf sabertooth z170 mark 1 [15/140] Installation tools and components

Installation tools and components

Graphics card (optional) Phillips (cross) screwdriver

PC chassis Power supply unit

Intel

LGA1151 CPU Intel

LGA1151 compatible CPU Fan

DIMM SATA hard disk drive

SATA optical disc drive (optional)

The tools and components in the table above are not included in the motherboard package.
