Asus tuf sabertooth z170 mark 1 [77/140] Chapter 3

SABERTOOTH Z170 MARK 1

3-7

Chapter 3

3.2.3 Q-Fan Control

The Q-Fan Control allows you to set a fan prole or manually congure the operating speed

of your CPU and chassis fans.

Click to select a fan to be

configured

Click to activate

PWM Mode

Click to undo

the changes

Click to apply the fan setting

Click to go back to main menu

Select a profile to

apply to your fans

Click to activate DC Mode

Select to manually

configure your fans
