Asus tuf sabertooth z170 mark 1 [56/140] Chapter 2

2-4

Chapter 2: Basic Installation

Chapter 2

Top of CPU

• EnsurethattheCPUisrmlyclickedintoplacebeforeinstallingitontotheCPUsocket

on the motherboard.

• UsetheCPUInstallationToolforinstallingtheCPUonly.DONOTdamageorbend

the CPU Installation Tool.

• AlwaysrmlyholdbothsidesoftheCPUInstallationToolwheninstalling,removing,or

picking up the CPU Installation Tool.

• ASUSwillnotcoverdamagesresultingfromincorrectCPUinstallation/removal,

incorrect CPU orientation/placement, or other damages resulting from negligence by

the user.
