xi
(continued on the next page)
SABERTOOTH Z170 MARK 1 specifications summary
Exclusive TUF Features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Armor with Flow Valve
- TUF Thermal Radar 2 with Thermistors
- TUF ICe
“We Got Your Back!” Shape Force
- TUF Fortier
“TUF ENGINE!” Power Design
- 8+4 Digital Phase Power Design
- TUF Components (10K Ti-Cap, TUF Chokes & MOSFET; certied
by military-standard)
- ASUS DIGI+ Power Control Utility
“Safe & Stable!” Guardian Angel
- TUF Detective 2
- TUF ESD Guards 2
- Dust Defenders with connector covers and back I/O dust lter
- MemOK!
Other Special Features
- USB 3.1 Boost featuring speedy USB 3.1 transmission
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ
BIOS download scheduling
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user
interface
- Turbo LAN to experience smooth online gaming with lower pings
and less lags
- AI Suite 3
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- EZ Update
- ASUS EZ Flash 3
- Multi-language BIOS
