Administrator’s Guide for CP860 IP conference phones
132
“c” (connection addresses for the media streams) in the SDP to zero (e.g., c=0.0.0.0).
Call hold tone allows IP phones to play a warning tone at regular intervals when there is
a call on hold. The warning tone is played through the speakerphone.
IP phones also support Music on Hold (MoH) feature. MoH is the business practice of
playing recorded music to fill the silence that would be heard by the party who has
been placed on hold. To use this feature, specify a SIP URI pointing to a MoH server
account. When a call is placed on hold, the IP phone will send an INVITE message to the
specified MoH server account according to the SIP URI. The MoH server account
automatically responds to the INVITE message and immediately plays audio from some
source located anywhere (LAN, Internet) to the held party.
Procedure
Call hold can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Configure the call hold tone and
call hold tone delay.
Parameters:
features.play_hold_tone.enable
features.play_hold_tone.delay
Specify whether RFC 2543
(c=0.0.0.0) outgoing hold
signaling is used.
Parameters:
sip.rfc2543_hold
<MAC>.cfg
Configure MoH on a per-line
basis.
Parameter:
account.X.music_server_uri
Local
Web User Interface
Configure the call hold tone and
call hold tone delay.
Specify whether RFC 2543
(c=0.0.0.0) outgoing hold
signaling is used.
Navigate to:
http://<phoneIPAddress>/servlet
?p=features-general&q=load
Configure MoH on a per-line
basis.
Navigate to:
http://<phoneIPAddress>/servlet
?p=account-adv&q=load&acc=
