Yealink CP860 [37/417] Details of configuration parameters
![Yealink CP860 [37/417] Details of configuration parameters](/views2/1192007/page37/bg25.png)
Getting Started
25
Procedure
Network parameters can be configured manually using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure network parameters of
the IP phone manually.
Parameters:
network.internet_port.type
network.ip_address_mode
network.internet_port.ip
network.internet_port.mask
network.internet_port.gateway
network.primary_dns
network.secondary_dns
Local
Web User Interface
Configure network parameters of
the IP phone manually.
Navigate to:
http://<phoneIPAddress>/servlet
?p=network&q=load
Phone User Interface
Configure network parameters of
the IP phone manually.
Details of Configuration Parameters:
Parameters
Permitted Values
Default
network.internet_port.type
0 or 2
0
Description:
Configures the Internet (WAN) port type for IPv4 when the IP address mode is
configured as IPv4 or IPv4&IPv6.
0-DHCP
2-Static IP Address
Note: If you change this parameter, the IP phone will reboot to make the change take
effect.
Web User Interface:
Network->Basic-> IPv4 Config
Phone User Interface:
Menu->Settings->Advanced Settings (Default password: admin) ->Network->WAN
Port->IPv4
network.ip_address_mode
0, 1 or 2
0
