Administrator’s Guide for CP860 IP conference phones
56
formats.
Parameters:
local_time.time_format
local_time.date_format
Local
Web User Interface
Configure NTP by DHCP priority
feature.
Configure the NTP server, time
zone and DST.
Configure the time and date
manually.
Configure the time and date
formats.
Navigate to:
http://<phoneIPAddress>/servlet
?p=settings-datetime&q=load
Phone User Interface
Configure the NTP server and
time zone.
Configure the time and date
manually.
Configure the time and date
formats.
Details of Configuration Parameters:
Parameters
Permitted Values
Default
local_time.manual_ntp_srv_prior
0 or 1
0
Description:
Enables or disables the IP phone to use manually configured NTP server
preferentially.
0-Disabled (use the NTP server obtained by DHCP preferentially)
1-Enabled (use the NTP server configured manually preferentially)
Web User Interface:
Settings->Time & Date->NTP By DHCP Priority
Phone User Interface:
None
local_time.dhcp_time
0 or 1
0
