Yealink CP860 [217/417] Details of configuration parameters
![Yealink CP860 [217/417] Details of configuration parameters](/views2/1192007/page217/bgd9.png)
Configuring Advanced Features
205
when receiving new voice messages.
IP phones support both solicited and unsolicited MWI. Unsolicited MWI is a server
related feature.
IP phone sends a SUBSCRIBE message to the server for message-summary updates.
The server sends a message-summary NOTIFY within the subscription dialog each time
the MWI status changes. For solicited MWI, you must enable MWI subscription feature
on IP phones. IP phones support subscribing the MWI messages to the account or the
voice mail number.
IP phones do not need to subscribe to message-summary updates. The server
automatically sends a message-summary NOTIFY in a new dialog each time the MWI
status changes.
Procedure
Configuration changes can be performed using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure subscribe for MWI.
Parameters：
account.X.subscribe_mwi
account.X.subscribe_mwi_expires
account.X.subscribe_mwi_to_vm
Configure subscribe MWI to voice
mail.
Parameter：
voice_mail.number.X
Local
Web User Interface
Configure subscribe for MWI.
Configure subscribe MWI to voice
mail.
Navigate to:
http://<phoneIPAddress>/servlet?p
=account-adv&q=load&acc=0
Details of Configuration Parameters:
Parameters
Permitted Values
Default
account.X.subscribe_mwi
(X = 1)
0 or 1
0
Description:
Enables or disables the IP phone to subscribe the message waiting indicator.
If it is set to 1 (Enabled), the IP phone will send a SUBSCRIBE message to the server
for message-summary updates.
