Administrator’s Guide for CP860 IP conference phones
336
5: normal but significant condition
6: informational
Procedure
Log setting can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Configures the syslog
mode.
Parameters:
syslog.mode
Configures the IP address
or domain name of the
syslog server where to
export the log files.
Parameters:
syslog.server
Configures the severity
level of the logs to be
reported to a log file.
Parameters:
syslog.log_level
Local
Web User Interface
Configures the syslog
mode.
Configures the IP address
or domain name of the
syslog server where to
export the log files.
Configures the severity
level of the logs to be
reported to a log file.
Navigate to:
http://<phoneIPAddress>/
servlet?p=settings-config
&q=load
Details of Configuration Parameters:
Parameters
Permitted Values
Default
syslog.mode
0 or 1
0
Description:
