Administrator’s Guide for CP860 IP conference phones
308
Procedure
Configuration changes can be performed using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure TLS.
Parameter:
account.X.transport
y000000000037.cfg
Configure the trusted
certificates feature.
Parameters:
security.trust_certificates
security.ca_cert
security.cn_validation
Configure the server certificates
feature.
Parameters:
security.dev_cert
Upload the trusted certificates.
Parameter:
trusted_certificates.url
Upload the server certificates.
Parameter:
server_certificates.url
Local
Web User Interface
Configure TLS.
Navigate to:
http://<phoneIPAddress>/servl
et?p=account-register&q=load
&acc=0
Configure the trusted
certificates feature.
Upload the trusted certificates.
Navigate to:
http://<phoneIPAddress>/servl
et?p=trusted-cert&q=load
Configure the server certificates
feature.
Upload the server certificates.
Navigate to:
http://<phoneIPAddress>/servl
