Yealink CP860 [265/417] Details of configuration parameters
![Yealink CP860 [265/417] Details of configuration parameters](/views2/1192007/page265/bg109.png)
Configuring Advanced Features
253
TLV Type
TLV Name
Description
Inventory –
Firmware Revision
Firmware revision of phone.
Inventory –
Software Revision
Software revision of phone.
Inventory – Serial
Number
Serial number of phone.
Inventory –
Manufacturer Name
Manufacturer name of phone.
The default value is “yealink”.
Inventory – Model
Name
Model name of phone.
Asset ID
Assertion identifier of phone.
The default value is “asset”.
Procedure
LLDP can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Configure LLDP feature.
Parameters:
network.lldp.enable
network.lldp.packet_interval
Local
Web User Interface
Configure LLDP feature.
Navigate to:
http://<phoneIPAddress>/servl
et?p=network-adv&q=load
Details of Configuration Parameters:
Parameters
Permitted Values
Default
network.lldp.enable
0 or 1
1
Description:
Enables or disables LLDP feature on the IP phone.
0-Disabled
1-Enabled
Note: If you change this parameter, the IP phone will reboot to make the change
take effect.
Web User Interface:
Network->Advanced->LLDP->Active
