Yealink CP860 [188/417] Details of configuration parameters
![Yealink CP860 [188/417] Details of configuration parameters](/views2/1192007/page188/bgbc.png)
Administrator’s Guide for CP860 IP conference phones
176
Intercom Mute
Intercom Mute allows the IP phone to mute the microphone for incoming intercom calls.
Intercom Tone
Intercom Tone allows the IP phone to play a warning tone before answering an intercom
call.
Intercom Barge
Intercom Barge allows the IP phone to automatically answer an incoming intercom call
while an active call is in progress. The active call will be placed on hold.
Procedure
Incoming intercom calls can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Configure the incoming intercom
call feature.
Parameters:
features.intercom.allow
features.intercom.mute
features.intercom.tone
features.intercom.barge
Local
Web User Interface
Configure the incoming intercom
call feature.
Navigate to:
http://<phoneIPAddress>/servlet
?p=features-intercom&q=load
Phone User Interface
Configure the incoming intercom
call feature.
Details of Configuration Parameters:
Parameters
Permitted Values
Default
features.intercom.allow
0 or 1
1
Description:
Enables or disables the IP phone to automatically answer an incoming intercom call.
0-Disabled
1-Enabled
If it is set to 0 (Disabled), the IP phone will reject incoming intercom calls and sends a
busy signal to the caller.
If it is set to 1 (Enabled), the IP phone will automatically answer an incoming
intercom call.
