Yealink CP860 [46/417] Details of configuration parameters
![Yealink CP860 [46/417] Details of configuration parameters](/views2/1192007/page46/bg2e.png)
Administrator’s Guide for CP860 IP conference phones
34
Procedure
Configuration changes can be performed using the configuration files or locally.
Configuration File
y000000000037.cfg
Configure the way for the IP phone
to check for configuration files.
Parameters：
auto_provision.power_on
auto_provision.repeat.enable
auto_provision.repeat.minutes
auto_provision.weekly.enable
auto_provision.weekly.begin_time
auto_provision.weekly.end_time
auto_provision.weekly.dayofweek
Specify the access URL of firmware.
Parameter:
firmware.url
Local
Web User Interface
Configure the way for the IP phone
to check for configuration files.
Navigate to:
http://<phoneIPAddress>/servlet?p
=settings-autop&q=load
Details of Configuration Parameters:
Parameters
Permitted Values
Default
auto_provision.power_on
0 or 1
1
Description:
Enables or disables the IP phone to perform an auto provisioning process when
powered on.
0-Disabled
1-Enabled
Web User Interface:
Settings->Auto Provision->Power On
Phone User Interface:
None
auto_provision.repeat.enable
0 or 1
0
