Configuring Audio Features
291
This chapter provides information for making configuration changes for the following
audio features:
Audio Codecs
Acoustic Clarity Technology
CODEC is an abbreviation of COmpress-DECompress, capable of coding or decoding a
digital data stream or signal by implementing an algorithm. The object of the algorithm
is to represent the high-fidelity audio signal with minimum number of bits while retaining
the quality. This can effectively reduce the frame size and the bandwidth required for
audio transmission.
The following table lists the audio codecs supported by CP860 IP conference phones:
Supported Audio Codecs
Default Audio Codecs
G722, PCMU, PCMA, G729, G723_53,
G723_63, G726_16, G726_24, G726_32,
G726_40, iLBC
G722, PCMU, PCMA, G729
The following table summarizes the supported audio codecs on IP phones:
Codec
Algorithm
Reference
Bit Rate
Sample
Rate
Packetization
Time
G722
G.722
RFC 3551
64 Kbps
16 KHz
20ms
PCMU
G.711
u-law
RFC 3551
64 Kbps
8 KHz
20ms
PCMA
G.711
a-law
RFC 3551
64 Kbps
8 KHz
20ms
G729
G.729
RFC 3551
8 Kbps
8 KHz
20ms
G726-16
G.726
RFC 3551
16 Kbps
8 Ksps
20ms
G726-24
G.726
RFC 3551
24 Kbps
8 Ksps
20ms
G726-32
G.726
RFC 3551
32 Kbps
8 Ksps
20ms
G726-40
G.726
RFC 3551
40 Kbps
8 Ksps
20ms
G723_53/
G723_63
G.723.1
RFC 3951
5.3kbps
6.3kbps
8 Ksps
30ms
iLBC
iLBC
RFC 3952
13.33 Kbps
8 KHz
20ms
30ms
