Configuring Advanced Features
193
remote phone book entries on the phone user interface. IP phones support up to 5
remote phone books and 5000 entries. Remote phone book is customizable. For more
information, refer to Remote XML Phone Book on page 331.
Sremote Name allows IP phones to search the entry names from the remote phone
book for incoming/outgoing calls. Sremote Name Flash Time defines how often IP
phones refresh the local cache of the remote phone book.
Procedure
Remote phone book can be configured using the configuration files or locally.
Configuration File
y000000000037.cfg
Specify the access URL and the display
name of the remote phone book.
Parameters:
remote_phonebook.data.X.url
remote_phonebook.data.X.name
Specify whether to query the entry name
from the remote phone book for
outgoing/incoming calls.
Parameter:
features.remote_phonebook.enable
Specify how often the IP phone refreshes
the local cache of the remote phone book.
Parameter:
features.remote_phonebook.flash_time
Local
Web User
Interface
Specify the access URL of the remote
phone book.
Navigate to:
http://<phoneIPAddress>/servlet?p=cont
acts-remote&q=load
Specify whether to query the entry name
from the remote phone book for
outgoing/incoming calls.
Navigate to:
http://<phoneIPAddress>/servlet?p=cont
acts-remote&q=load
Specify how often the IP phone refreshes
the local cache of the remote phone book.
Navigate to:
http://<phoneIPAddress>/servlet?p=cont
acts-remote&q=load
