Administrator’s Guide for CP860 IP conference phones
184
Parameters
Permitted Values
Default
Description:
Configures the internal ringer text to map the keywords contained in the Alert-Info
header.
Example:
distinctive_ring_tones.alert_info.1.text = family
Web User Interface:
Settings->Ring->Internal Ringer Text
Phone User Interface:
None
distinctive_ring_tones.alert_info.X.ringer
(X ranges from 1 to 10)
String within 32 characters
1
Description:
Configures the desired ring tones for each text.
The value ranges from 1 to 5, the digit stands for the appropriate ring tone.
1-Ring1.wav
2-Ring2.wav
3-Ring3.wav
4-Ring4.wav
5-Ring5.wav
Web User Interface:
Settings->Ring->Internal Ringer Text
Phone User Interface:
None
To configure distinctive ring tones via web user interface:
1. Click on Account-> Advanced.
