Moxa V2406A-C7-CT-T [80/85] Warning

V2406A W7E Series System Recovery

8-14

5. Choose whether to power down the computer (press 0), reboot (press 1), access the console terminal (to

access a console TTY, press 2), or re-initiate the entire procedure (press 3).

WARNING

Do NOT remove the USB drive from the computer until you have rebooted or powered down the system.

6. Power down the system and remove the USB drive.

The recovery environment setup is complete and you have created an OS image in the USB

Folder\home\partimag\os_image folder. Label the USB drive and store it in a safe place.
