TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-12
-- 1.3.6.1.4.1.8691.17.1.6.1.1.2.1.3
diValue OBJECT-TYPE
SYNTAX INTEGER
{
low(0),
high(1)
}
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"The digital input status, 0 is low, 1 is high."
::= { ioDiEntry 3 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.2.1.4
diTrapEnable OBJECT-TYPE
SYNTAX INTEGER
{
disable(0),
enable(1)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Agent will send trap message when digital input pin status changed
and this object enbeled."
::= { ioDiEntry 4 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.3
ioDoNumber OBJECT-TYPE
SYNTAX Integer32 (0..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Number of digital output pin in current system."
::= { ioObject 3 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.4
ioDoTable OBJECT-TYPE
SYNTAX SEQUENCE OF IoDoEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Table of digital output and their values."
::= { ioObject 4 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.4.1
ioDoEntry OBJECT-TYPE
SYNTAX IoDoEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing a digital output pin and its statistics."
INDEX { doIndex }
::= { ioDoTable 1 }
