TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-13
IoDoEntry ::=
SEQUENCE {
doIndex
Integer32,
doPort
Integer32,
doValue
INTEGER
}
-- 1.3.6.1.4.1.8691.17.1.6.1.1.4.1.1
doIndex OBJECT-TYPE
SYNTAX Integer32 (1..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Reference index for each digital output pin."
::= { ioDoEntry 1 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.4.1.2
doPort OBJECT-TYPE
SYNTAX Integer32 (0..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"The port number of digital output pin."
::= { ioDoEntry 2 }
-- 1.3.6.1.4.1.8691.17.1.6.1.1.4.1.3
doValue OBJECT-TYPE
SYNTAX INTEGER
{
low(0),
high(1)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The digital output status, 0 is low, 1 is high."
::= { ioDoEntry 3 }
-- 1.3.6.1.4.1.8691.17.1.6.1.2
ioNotification OBJECT IDENTIFIER ::= { perIoMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.6.1.2.1
ioDiChange NOTIFICATION-TYPE
STATUS current
DESCRIPTION
"This trap is sent when digital input pin status changed."
::= { ioNotification 1 }
-- 1.3.6.1.4.1.8691.17.1.6.2
perLedMgmt OBJECT IDENTIFIER ::= { peripheralMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.6.2.1
