TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-15
-- 1.3.6.1.4.1.8691.17.1.6.2.2.1.3
ledValue OBJECT-TYPE
SYNTAX INTEGER
{
off(0),
on(1)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Description."
::= { ledEntry 3 }
-- 1.3.6.1.4.1.8691.17.1.6.3
perSerialMgmt OBJECT IDENTIFIER ::= { peripheralMgmt 3 }
-- 1.3.6.1.4.1.8691.17.1.6.3.1
uartNumber OBJECT-TYPE
SYNTAX Integer32 (0..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Number of internal UART in current system."
::= { perSerialMgmt 1 }
-- 1.3.6.1.4.1.8691.17.1.6.3.2
uartConfigTable OBJECT-TYPE
SYNTAX SEQUENCE OF UartConfigEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Table of internal UART and their values."
::= { perSerialMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.6.3.2.1
uartConfigEntry OBJECT-TYPE
SYNTAX UartConfigEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"An entry containing a UART port and its statistics."
INDEX { uartIndex }
::= { uartConfigTable 1 }
UartConfigEntry ::=
SEQUENCE {
uartIndex
Integer32,
uartType
INTEGER
}
-- 1.3.6.1.4.1.8691.17.1.6.3.2.1.1
uartIndex OBJECT-TYPE
SYNTAX Integer32 (1..65535)
