TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-16
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"Reference index for each UART port."
::= { uartConfigEntry 1 }
-- 1.3.6.1.4.1.8691.17.1.6.3.2.1.2
uartType OBJECT-TYPE
SYNTAX INTEGER
{
rs232(0),
rs485w2(1),
rs422(2),
rs485w4(3)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"The UART
mode, 0 is RS232, 1 is RS485 2 wires, 2 is RS422, 3 is RS485
4 wires."
::= { uartConfigEntry 2 }
-- 1.3.6.1.4.1.8691.17.1.6.4
perUsbMgmt OBJECT IDENTIFIER ::= { peripheralMgmt 4 }
-- 1.3.6.1.4.1.8691.17.1.6.4.1
usbObject OBJECT IDENTIFIER ::= { perUsbMgmt 1 }
-- 1.3.6.1.4.1.8691.17.1.6.4.1.1
usbNumber OBJECT-TYPE
SYNTAX Integer32 (0..65535)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"The number of ports regardless of their current state
in the usb general port table"
::= { usbObject 1 }
-- 1.3.6.1.4.1.8691.17.1.6.4.1.3
usbDeviceTable OBJECT-TYPE
SYNTAX SEQUENCE OF UsbDeviceEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"A list of USB device ports. Usually the device has
only one USB device port"
::= { usbObject 3 }
-- 1.3.6.1.4.1.8691.17.1.6.4.1.3.1
usbDeviceEntry OBJECT-TYPE
SYNTAX UsbDeviceEntry
MAX-ACCESS not-accessible
STATUS current
DESCRIPTION
"Status and parameter values for the USB device port."
