TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-18
DESCRIPTION
"This object returns USB Device Class type of the
active configuration"
::= { usbDeviceEntry 4 }
-- 1.3.6.1.4.1.8691.17.1.6.4.1.4
usbPlugTrapEnable OBJECT-TYPE
SYNTAX INTEGER
{
disable(0),
enable(1)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Agent will send trap message when USB device inserted or removed and
this object enbeled."
::= { usbObject 4 }
-- 1.3.6.1.4.1.8691.17.1.6.4.2
usbNotification OBJECT IDENTIFIER ::= { perUsbMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.6.4.2.1
usbPlugEvent NOTIFICATION-TYPE
STATUS current
DESCRIPTION
"This trap is sent when USB device inserted or removed."
::= { usbNotification 1 }
-- 1.3.6.1.4.1.8691.17.1.6.6
perSystemMgmt OBJECT IDENTIFIER ::= { peripheralMgmt 6 }
-- 1.3.6.1.4.1.8691.17.1.6.6.2
systemWatchdog OBJECT IDENTIFIER ::= { perSystemMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.6.6.2.1
watchdogPeriod OBJECT-TYPE
SYNTAX Second (0..255)
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Watchdog period, 0 means disable watchdog monitor program; otherwise
enable watchdog monitor program and configure the expired time."
::= { systemWatchdog 1 }
-- 1.3.6.1.4.1.8691.17.1.6.6.2.2
watchdogStatus OBJECT-TYPE
SYNTAX INTEGER
{
running(1),
stopped(2)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
