TC-6110 Linux User's Manual Moxa MIB File for TC-6110-LX
B-19
"To show the watchdog monitor program status."
::= { systemWatchdog 2 }
-- 1.3.6.1.4.1.8691.17.1.7
powerMgmt OBJECT IDENTIFIER ::= { moxaSystem 7 }
-- 1.3.6.1.4.1.8691.17.1.7.2
powerPolicy OBJECT-TYPE
SYNTAX INTEGER
{
balanced(1),
power_saver(2),
high_performance(3)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Current system power policy."
::= { powerMgmt 2 }
-- 1.3.6.1.4.1.8691.17.1.9
notificationMgmt OBJECT IDENTIFIER ::= { moxaSystem 9 }
-- 1.3.6.1.4.1.8691.17.1.9.1
moxaSystemTrapIP OBJECT-TYPE
SYNTAX IpAddress
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Set Trap IP address. eg. 192.168.1.100"
::= { notificationMgmt 1 }
-- 1.3.6.1.4.1.8691.17.1.9.2
moxaSystemTrapCommunity OBJECT-TYPE
SYNTAX OCTET STRING (SIZE (0..127))
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Trap community. eg. public"
::= { notificationMgmt 2 }
END
--
-- MOXA-SYS-MIB.txt
--
