W321/341 Linux Getting Started
2-5
root@Moxa:# iwpriv wlan0 get_site_survey
wlan0 get_site_survey:
Ch SSID
BSSID Security Siganl(%)W-Mode ExtCH NT
1 MIS-WAP-1 50:67:f0:61:2d:7a WEP 55 11b/g NONE In
If you want to get more detailed info, type the following command:
#iwlist wlan0 scanning
root@Moxa:# iwlist wlan0 scanning
wlan0 Scan completed :
Cell 01 - Address: 50:67:F0:61:2D:7A
Protocol:802.11b/g
ESSID:"MIS-WAP-1"
Mode:Managed
Frequency:2.412 GHz (Channel 1)
Quality=81/100 Signal level=-58 dBm Noise level=-92 dBm
Encryption key:on
Bit Rates:54 Mb/s
NOTE
W321/341 only supports 2.4GHz Wi-Fi, which means only 802.11 b/g/n with 2.4GHz is available.
Using WPA_SUPPLICANT to configure WPA2
This embedded computer supports WPA2 security using the /bin/wpa_supplicant program.
Refer to the following table to determine the configuration options. The column labeled "Key required before
joining network?" describes whether an encryption and/or authentication key must be configured before
associating with a network.
Infrastructure
mode
Authentication
mode
Encryption
status
Manual Key
required?
IEEE 802.1X
enabled?
Key required
before joining
network?
ESS Open None No No No
ESS Open WEP Optional Optional Yes
ESS Shared None Yes No Yes
ESS Shared WEP Optional Optional Yes
ESS WPA WEP No Yes No
ESS WPA TKIP No Yes No
ESS WPA AES No Yes No
ESS
WPA-PSK
WEP
Yes
Yes
No
ESS WPA-PSK TKIP Yes Yes No
ESS WPA-PSK AES Yes Yes No
IBSS
Open
None
No
No
No
IBSS Open WEP Yes No Yes
IBSS Shared None Yes No Yes
IBSS Shared WEP Yes No Yes
IBSS WPA-None WEP Yes No Yes
IBSS WPA-None TKIP Yes No Yes
IBSS WPA-None AES Yes No Yes
See the following section for the shell script to use this function.
Connecto to an AP via WEP shared key authentication
Step 1: Edit /etc/Wireless/wpa_supplicant.conf.
