W321/341 Linux Managing Embedded Linux
3-10
Cron—Daemon to Execute Scheduled
Commands
Start Cron from the directory /etc/rc.d/rc. local. It will return immediately, so you don’t need to start it
with ‘&’ to run in the background.
The Cron daemon will search /etc/cron.d/crontab for crontab files, which are named after accounts in
/etc/passwd.
Cron wakes up every minute, and checks each command to see if it should be run in that minute. Modify
the file /etc/cron.d/crontab to set up your scheduled applications. Crontab files have the following
format:
mm
h
dom
mon
dow
user
command
min
hour
date
month
week
user
command
0-59
0-23
1-31
1-12
0-6 (0 is Sunday)
The following example demonstrates how to use Cron.
How to use cron to update the system time and RTC time every day at 8:00.
STEP1: Write a shell script named fixtime.sh and save it to /home/.
#!/bin/sh
ntpdate time.nist.gov
hwclock –-systohc
exit 0
STEP2: Change mode of fixtime.sh
#chmod 755 fixtime.sh
STEP3: Modify /etc/cron.d/crontab file to run fixtime.sh at 8:00 every day.
Add the following line to the end of crontab:
* 8 * * * root/homefixtime.sh
STEP4: Enable the cron daemon manually.
#/etc/init.d/cron start
STEP5: Enable cron when the system boots up.
Add the following line in the file /etc/init.d/rc.local
#/etc/init.d/cron start
