W321/341 Linux Managing Embedded Linux
3-13
fi
fi
exit 0
If you need to customize the mounting script, you should change root file system partition to
writable mode for editing /sbin/automount.sh script.
root@Moxa:/# mount -o remount,rw /
root@Moxa:/# vi /sbin/automount_sd.sh
root@Moxa:/# umount /
